Brands: Martin Audio

SXCF115

SXCF115

Compact, High Performance Cardioid Subwoofer

Designed for touring sound and installations, the SXCF115 is a compact, high performance cardioid subwoofer which be flown as part of a WPM or TORUS 8 array, or ground-stacked separately.

WHERE TO BUY

Features

  • Compact, cardioid subwoofer
  • Front facing 15” (380mm)/4” (100mm) voice coil driver
  • Rear facing 12” (300mm)/4” (100mm) voice coil driver
  • Cardioid dispersion pattern
  • 28dB rear rejection at 75Hz
  • High output capability
  • Tour-grade plywood enclosure

Applications

  • Live sound reinforcement
  • Fixed installations including live event venues and nightclubs
  • Theatre sound
  • Corporate AV events
  • Acoustically-challenging rooms

SXCF115 features a 15” (380mm) forward facing driver and a 12” (300mm) rear facing driver, each driven independently by separate amplifier channels and DSP. Each driver has its own chamber with optimised bass reflex porting. This arrangement produces a cardioid dispersion pattern which maximises the front radiation and reduces unwanted radiation behind the subwoofer.

The recommended iK42 amplifier optimises the DSP parameters for front and rear drivers to maximise the rear rejection — from 21dB at 43Hz to 28dB at 75Hz. This keeps low frequencies away from stages and walls as well as reducing reverberant energy in the room — greatly improving the low frequency response accuracy and impact of the whole system.

In front of the enclosure, the output from the two drivers is additive, delivering 137dB peak, an extra 2dB of output when compared with a conventional 1 x 15” subwoofer.

The SXCF115 integrates perfectly with WPM flown line arrays and TORUS 8 constant curvature arrays, as well an accompaniment for Martin Audio point source systems where low frequency pattern control is required. It can be used singly, stacked or flown, supported by accessories.

The enclosure is constructed from birch ply and finished with a hard-wearing textured paint. It is equipped with four grab handles and foam-backed perforated steel grilles protect the front and rear drivers. Interlocking skids prevent movement when stacked and a threaded plate in the top surface facilitates pole-mounting.

The addition of the input cover accessory makes the SXCF115 weather resistant and suitable for outdoor usage.

USER GUIDE
DATASHEET
Edit Content

WPMSXGRIDT / WPMSXGRIDT-W

Touring Flying Frame for WPM and SXCF115

DATASHEET

WHEEL KIT

Pack of four
4 x Wheels

DATASHEET

ASF20071

Wind-up
telescopic pole

DATASHEET

wrkit

Weatherised Kit
Option

DATASHEET

HTKCT06

M10 Eye Bolt
10mm

DATASHEET

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us

Torus T820

T820

Passive, Two-way, Constant Curvature Array Element

TORUS T820 is a passive, two-way loudspeaker engineered for small to medium-scale applications which do not call for the longer throw capabilities of a line array. With exceptional ease-of-use, scalability and deployment flexibility, it is primarily used as an array element in vertical constant curvature arrays as well as being used singly as a point-source loudspeaker. In venues with short throws, yet high ceilings like some theatres, a horizontal centre cluster may also be a practical solution.

WHERE TO BUY

Features

  • Two-way, constant curvature array element
  • Compact enclosure with high output capability
  • 1 x 8” (200mm) LF driver plus 2 x 1.4” (35mm)/1” (25mm) exit HF drivers
  • 100° horizontal dispersion x 20° vertical dispersion
  • Easy-to-use integral rigging for quick set-up
  • Integral fittings to facilitate pole-mounting
  • Optimised coverage via DISPLAY 3
  • Powered by iKON amplifiers

Applications

  • Short to medium-throw live sound
  • Theatre sound
  • Fixed installations
  • Fills, centre clusters and delays
  • Portable DJ and corporate events

T820 combines impressive output capability, superb sonic performance and a defined 100° by 20° coverage pattern from a very compact enclosure. Its small size and portability extend its range of applications from live sound and permanent installations to corporate events, gigging musicians and DJ’s.

A phase plug is mounted in front of an 8” neodymium driver to increase midband sensitivity while two 1” exit, 1.4” voice coil high temperature polymer dome neodymium compression drivers ensure sonic performance is not compromised even when driven at higher SPL.

Its durable plywood is enclosure finished in hardwearing textured paint and incorporates two pocket handles for easy installation and deployment, as well as fixings for pole-mounting. A full width steel grille with a cloth backing protects the drivers and presents a discreet, professional appearance. Easy-to-use integral rigging hardware supports construction of both vertical and horizontal arrays of up to 6 enclosures in conjunction with comprehensive flying frames and rigging accessories.

T820 feature two NL4 connectors with passive configuration using pins 1+ 1- or 2+ 2- selected via rear-mounted switch. Systems are powered by Martin Audio iKON amplifiers, which support VU-NET control software and Dante® integration.T820 also feature a LED indicator that can be illuminated via VU-NET software to identify its location on the network. With DISPLAY 3 software, TORUS systems can be modelled in 3D with optimising filters to deliver consistent and defined coverage.

T820 can be supplemented by Martin Audio SX subwoofers and is designed to integrate mechanically with the SXCF115 cardioid subwoofer in flown and groundstack configurations.

T820 is available as standard in black (T820B) or white (T820W).

DATASHEET
TORUS - T8
Edit Content

POLERIG20

Pole-mount bracket
for T8 cabinets

DATASHEET

SBAR40/
SBAR40-W

Flying Bracket for up to two T8 or
a single T12, available in black or white

DATASHEET

HRIG100 /
HRIG100-W

Modular flying bar for horizontal arrays
arrays, available in black or white

DATASHEET

GSRIG20 / GSRIG20-W

Ground-stack frame for T8 cabinets to
SXCF115, available in black or white

DATASHEET

T8GRID / T8GRID-W

Flying frame for vertical T8 arrays, available in black or white

DATASHEET

T8PB / T8PB-W

Simple rigging bar for vertical arrays of T8 cabinets, available in black or white

DATASHEET

IK42AMPRACK-UK+

Amplifier rack
for iK42

DATASHEET

IK42DIST32UK+

Distro for iK42
ROW version

DATASHEET

IK42DIST32US+

Distro for iK42
US version

DATASHEET

AMPRACK9UUK

9U amplifier rack
for iK42 and iK81

DATASHEET

INDIST1U+

Distro panel for
iKON amplifier racks

DATASHEET

ASF20071

Wind-up
telescopic pole

DATASHEET
Edit Content

SXCF115

15″ PASSIVE CARDIOID FLOWN SUBWOOFER

Compact, High Performance

MORE INFO
DATASHEET
user guide

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us

PI218

PI218

Dual-Driver Subwoofer

The PI218 is a dual-driver, high performance subwoofer for use with P.I. Series full-range loudspeakers.

WHERE TO BUY

Features

  • Dual-driver, direct radiator subwoofer
  • 2 x 18” (460mm) drivers with 4” (100mm) voice coils
  • Durable plywood enclosure
  • Large ports for reduced air noise
  • Powder coated, perforated steel grille
  • Integral ergonomic handles
  • 35mm pole-mount socket
  • Feet for vertical or horizonal operation
  • Rebate recesses for stable horizontal stacking
  • M10 flying inserts

Applications

  • Portable sound reinforcement
  • Live music clubs
  • Bars and restaurants
  • Nightclubs
  • Corporate AV events and conferences
  • Weddings and parties
  • Secondary stages at festivals
  • HoW, leisure centres and retail outlets

With an operating range of 42Hz-200Hz + 3dB, it produces high output levels with low distortion and can be used singly or stacked horizontally. It features dual 18” (460mm)/4” (100mm) voice coil, long excursion drivers in a reflex enclosure with eight large ports that reduce air turbulence at high output levels.

The PI218 enclosure is constructed from plywood and finished in black textured paint as standard. Integral M10 inserts provide for eyebolt suspension of a single enclosure. Ergonomic handles assist ease of handling and the drivers are protected by a perforated steel grille. Rubber feet on the base of the PI218 resist movement and align with recesses in the top surface for stable horizontal stacking. Feet are also provided on one side of the enclosure for vertical operation of a single cabinet.

BROCHURE
DATASHEET
Edit Content

VIA2502

2-CHANNEL CLASS D AMPLIFIER
LIGHTWEIGHT 2U RACK HEIGHT

450 Watts/Channel @ 8 Ohms

Edit Content

DX0.5

DSP-BASED
SYSTEM CONTROLLER

2-in-6-out

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us

PI118

PI118

Compact, Direct Radiating Subwoofer

The PI118 is a compact, high performance subwoofer for indoor use with P.I Series full-range loudspeakers.

WHERE TO BUY

Features

  • Compact, direct radiating subwoofer
  • 18” (460mm)/4” (100mm) voice coil, long excursion
  • High output capability
  • Plywood enclosure with flying inserts

Applications

  • Live sound reinforcement and portable systems
  • Stage monitors and sidefills
  • Theatre sound
  • Corporate AV events
  • Fixed installations in Government, Education, Museums, Hotels and hospitality

It extends the low frequency operating range of the combined system down to 42Hz and can be used singly, stacked in omni or cardioid mode, or flown via integral M10 insets. It features a long-excursion 18” (460mm)/4” (100 mm) voice coil driver in a compact enclosure that has four reflex ports with a large frontal area to reduce turbulent air noise at very high levels.

The PI118 enclosure is constructed from durable plywood and finished in textured black paint. A perforated steel grille protects the driver, and the enclosure two ergonomic side handles.

BROCHURE
DATASHEET
Edit Content

VIA2502

2-CHANNEL CLASS D AMPLIFIER
LIGHTWEIGHT 2U RACK HEIGHT

450 Watts/Channel @ 8 Ohms

Edit Content

DX0.5

DSP-BASED
SYSTEM CONTROLLER

2-in-6-out

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us

PI15

PI15

Compact, Two-way Passive System

The PI15 is a high-power, passive two-way system designed applications bars that require performance and output from a single enclosure.

WHERE TO BUY

Features

  • Full-range, passive two-way system
  • LF driver with demodulating ring for distortion-free vocals
  • User-rotatable horn
  • Vertical and horizontal mounting option
  • Cloth-backed perforated steel grille
  • Trapezoid enclosure with textured finish
  • 8Ω nominal impedance
  • Internal crossover network with LF and HF driver protection
  • Twin NL4 connectors
  • Multiple M8 rigging inserts

Applications

  • Education
  • Hospitality
  • Small performance spaces
  • Government
  • Public Spaces

It features a powerful 15” (380mm)/3” (75mm) voice coil LF drive unit, and a 1” (25mm) exit HF compression driver with a 1.75” (44mm) polyimide diaphragm for extended high frequency response. Its 80° x 50° coverage pattern is ideal for medium-throw applications, and it delivers superior vocal performance at very high sound levels without harshness.

The enclosure is constructed from 15mm engineered wood fibre and finished in black textured paint. A cloth-backed protective steel grille protects the drivers, and M8 inserts are provided for eyebolt suspension and installation.



BROCHURE
DATASHEET
Edit Content

VIA2502

2-CHANNEL CLASS D AMPLIFIER
LIGHTWEIGHT 2U RACK HEIGHT

450 Watts/Channel @ 8 Ohms

Edit Content

DX0.5

DSP-BASED
SYSTEM CONTROLLER

2-in-6-out

Edit Content

PI118

SUBWOOFER

Compact, Direct Radiating

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us

PI12

PI12

Compact, Two-way Passive System

The PI12 is a high-performance, two-way system with a maximum SPL of 129dB peak @ 1m. It features a 12” (300mm)/2.5” (63mm) voice coil LF driver unit and a 1” (25mm) exit compression driver with a 1.4” (35mm) polyimide diaphragm on a rotatable 80° x 50° HF horn.

WHERE TO BUY

Features

  • Full-range, passive two-way system
  • LF driver with demodulating ring for distortion-free vocals
  • User-rotatable horn
  • Vertical and horizontal mounting option
  • Cloth-backed perforated steel grille
  • Trapezoid enclosure with textured finish
  • 8Ω nominal impedance
  • Internal crossover network with LF and HF driver protection
  • Twin NL4 connectors
  • Multiple M8 rigging inserts

Applications

  • Education
  • Hospitality
  • Small performance spaces
  • Government
  • Public Spaces

The trapezoid enclosure is constructed from 15mm engineered wood fibre and finished in a textured black paint. It is fitted with a cloth-backed protective steel grille and M8 inserts are provided for eyebolt suspension and installation.

BROCHURE
DATASHEET
Edit Content

VIA2502

2-CHANNEL CLASS D AMPLIFIER
LIGHTWEIGHT 2U RACK HEIGHT

450 Watts/Channel @ 8 Ohms

Edit Content

DX0.5

DSP-BASED
SYSTEM CONTROLLER

2-in-6-out

Edit Content

PI118

SUBWOOFER

Compact, Direct Radiating

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us

PI10

PI10

Compact, Two-way Passive System

The PI10 is very compact, two-way passive loudspeaker designed for quality sound over short throw distances. It utilises a 10” (250mm)/2.5” (63mm) voice coil LF driver and a 1” (25mm) exit HF compression driver with a 1.4” (35mm) polyimide diaphragm.

WHERE TO BUY

Features

  • Full-range, passive two-way system
  • LF driver with demodulating ring for distortion-free vocals
  • User-rotatable horn
  • Vertical and horizontal mounting option
  • Cloth-backed perforated steel grille
  • Trapezoid enclosure with textured finish
  • 8Ω nominal impedance
  • Internal crossover network with LF and HF driver protection
  • Twin NL4 connectors
  • Multiple M8 rigging inserts

Applications

  • Education
  • Hospitality
  • Small performance spaces
  • Government
  • Public Spaces

It is capable of high output levels for its small size and its rotatable 90° x 50° HF horn provides extremely smooth coverage. Equal horizontal and vertical horn mouth dimensions ensure its excellent directivity control is maintained in both planes. The trapezoid enclosure is constructed from 15mm engineered wood fibre and finished in a textured black paint. It is fitted with a cloth-backed protective steel grille and M8 inserts are provided for eyebolt suspension and installation.

BROCHURE
DATASHEET
Edit Content

VIA2502

2-CHANNEL CLASS D AMPLIFIER
LIGHTWEIGHT 2U RACK HEIGHT

450 Watts/Channel @ 8 Ohms

Edit Content

DX0.5

DSP-BASED
SYSTEM CONTROLLER

2-in-6-out

Edit Content

PI118

SUBWOOFER

Compact, Direct Radiating

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us

PI8

PI8

Compact, Two-way Passive System

The PI8 is an ultra-compact two-way passive loudspeaker system with an integrated 8” (200mm) /2” (50mm) voice coil LF driver and a 1” (25mm) HF driver. Its very small size belies its high output capability.

WHERE TO BUY

Features

  • Full-range, passive two-way system
  • LF driver with demodulating ring for distortion-free vocals
  • User-rotatable horn
  • Vertical and horizontal mounting option
  • Cloth-backed perforated steel grille
  • Trapezoid enclosure with textured finish
  • 8Ω nominal impedance
  • Internal crossover network with LF and HF driver protection
  • Twin NL4 connectors
  • Multiple M8 rigging inserts

Applications

  • Education
  • Hospitality
  • Small performance spaces
  • Government
  • Public Spaces

PI8 can deliver pristine sound over short and medium throw distances and its rotatable 90° x 50° HF horn provides extremely smooth coverage in either plane. The trapezoid enclosure is constructed from 15mm engineered wood fibre and finished in a textured black paint. It is fitted with a cloth-backed protective steel grille and M8 inserts are provided for eyebolt suspension and installation.

BROCHURE
DATASHEET
Edit Content

VIA2502

2-CHANNEL CLASS D AMPLIFIER
LIGHTWEIGHT 2U RACK HEIGHT

450 Watts/Channel @ 8 Ohms

Edit Content

DX0.5

DSP-BASED
SYSTEM CONTROLLER

2-in-6-out

Edit Content

PI118

SUBWOOFER

Compact, Direct Radiating

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us

P.I. Series

P.I. Series

Passive Two-way Loudspeakers

everyday full-range loudspeakers and subwoofers

SIGNATURE SOUND FOR INSTALLATION

With the P.I. Series, Martin Audio engineers have designed a range of everyday full-range point source loudspeakers and subwoofers, specifically for small-medium installations such education, hospitality, performance venues and government buildings.

P.I. is exclusively distributed by Guangzhou Guidance AV Technology Ltd for the China market.

Four, passive two-way systems — the PI8, PI10, PI12 and PI15 —combine the Martin Audio signature sound of warmth, clarity and smooth response with the simplicity of easy installation. Additional bass can be achieved by complementing the system with either the PI118 or PI218 subwoofers.

P.I. Series enclosure features a user-rotatable horn for vertical or horizontal orientation and multiple M8 threaded inserts for easy installation. The trapezoid enclosures are braced internally to reduce panel resonances and improve sonic performance and are finished in a textured black paint, with drivers protected by a perforated steel grille.

The LF drivers have demodulating rings providing clear, distortion-free reproduction, even at high SPL and internal crossover networks incorporate technology to protect the low and high frequency drivers and assure reliability without interrupting the performance.

BROCHURE

ABOUT THE BRAND

Martin Audio enjoys an international reputation for supplying award winning, Patent protected professional loudspeaker systems across the spectrum of live sound and installation applications. It is now also the recognised global leader in optimised line array technology.
learn more

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us

TORUS T1230

T1230

Passive, 30° Fixed Angle Array Cabinet

For applications that typically require a throw between 15-30m, a full-blown line array is not always practical, optimal or affordable. Conversely, a point source solution may not be sufficient in coverage and SPL. TORUS is a constant curvature array, designed to fill that gap perfectly, combining optimised coverage, SPL and cost efficiency.

T1230 offers a vertical pattern of 30° with a flexible horizontal pattern that can be manually adjusted between 90°, 60° or 75° (Asymmetrical) via the Dynamic Horn Flare™.

WHERE TO BUY
t1230-side
t1230-front
Previous
Next

Features

  • 1 x 12” (300mm), & 3 x 1.4” (35mm) HF drivers
  • Passive fixed angle array cabinet of 30° vertical dispersion pattern
  • Manually adjustable Dynamic Horn Flare™ (between 60°, 90° or 75° Asymmetrical) for flexible horizontal pattern
  • Phase plug for increased mid-band sensitivity
  • Optimised coverage via DISPLAY 3 and powered by iKON amplifiers
  • Plug-and-play system, quick set-up and easy rigging

Applications

  • Optimised for short to medium-throw live sound and installation applications
  • Fills, distributed systems, and centre clusters

T1230 features a 12” (300mm) LF driver and three 1.4” (35mm) HF drivers and includes two NL4 connectors with passive configuration using pins 1+ 1- or 2+ 2- selected via rear-mounted switch. The plywood cabinets are finished in hardwearing Warnex paint with well positioned handles for easy installation and deployment. The integrated rigging suitable for install and touring applications and support horizontal array configurations of up to 180° with a flying frame that can support up to 6 cabinets in vertical orientation. The cabinets also feature a fixing for an external pole-mount accessory, increasing the flexibility to the max. In addition, T1230 can be supplemented by SX subwoofers and designed to fully integrate with the cardioid subwoofer, SXCF118, for flown and groundstack configurations.

Powered by Martin Audio iKON amplifiers, which support VU-NET and Dante®, T1230 can be modelled in 3D and optimised using DISPLAY 3, allowing different box resolutions as well as automatically optimising filtering to deliver consistent and defined coverage.

Available as standard in black (T1230B) or white (T1230W).

BROCHURE
DATASHEET
Edit Content

VIA2502

2-CHANNEL CLASS D AMPLIFIER
LIGHTWEIGHT 2U RACK HEIGHT

450 Watts/Channel @ 8 Ohms

Edit Content

VIA2502

2-CHANNEL CLASS D AMPLIFIER
LIGHTWEIGHT 2U RACK HEIGHT

450 Watts/Channel @ 8 Ohms

ARE YOU INTERESTED TO LEARN MORE ABOUT MARTIN AUDIO?

Speak to one of our Consultants now

speak to us
