Sub 15

Sub 15

High-power sub-bass loudspeaker

Sub 15 is a compact, high-performance, passive, 15” subwoofer designed for applications that call for increased impact and low frequency performance across the Optimal Audio loudspeaker range.

The 15” (380mm) driver is loaded into a plywood bass-reflex cabinet that maximises performance, with a peak SPL of 135dB, while taking up minimal space. Sub 15 can be used on the ground or flown using integral M8 inserts.

An impact-resistant perforated steel grille protects the driver, and rubber feet on the base resist movement. The Sub 15 enclosure is constructed from plywood and finished in black textured paint.

Features

  • Compact size
  • Powerful sub-bass support down to 40Hz (-10dB)
  • High power handling

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential

Sub 10

Sub 10

Low-profile sub-bass loudspeaker

Sub 10 is a slimline, passive 10” subwoofer designed for applications that call for increased impact and low frequency performance to the smaller Optimal Audio loudspeaker range. This visually unobtrusive enclosure makes it perfectly suited where space is limited such as under banquette seating.

It features a 10” (250mm) driver with a generously sized low frequency port for reduced air noise. With a peak SPL of 127dB this is a truly punchy little sub and can be used on the ground, fixed to a wall or ceiling or flown using integral M8 inserts.

An impact-resistant perforated steel grille protects the driver, and rubber feet on the base resist movement. The Sub 10 enclosure is constructed from plywood and finished in black textured paint.

Features

  • Discreet size
  • Punchy sub-bass extension
  • Ideal where space is limited
  • Great Sub support for smaller systems

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential

Sub

Sub

Subwoofers

The Sub series is designed for applications that call for increased impact and low frequency performance to the Optimal Audio loudspeaker range.

An impact-resistant perforated steel grille protects the driver in each case, and rubber feet on the base resist movement.

The enclosures are constructed from plywood and finished in black textured paint.

They can be installed on the ground, fixed to a wall or ceiling or flown.

Features

  • Compact dimensions for greater placement options
  • Punchy bass performance
  • Plywood cabinets and Impact resistant steel grille

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential

Cuboid 15

Cuboid 15

Two-way, full range, passive, 15" loudspeaker

Cuboid 15 is a full range, two-way, passive, 15” loudspeaker designed to perform. For any applications requiring big output, it effortlessly delivers rich and detailed sound with extra punch and precision.

With its steel grille and optional mounting hardware the professionally presented Cuboid 15 can be fixed in either portrait or landscape mode for a flexible, simple installation.

Cuboid 15 features a 15” (380mm) low frequency (LF) driver – for extra bass performance and mid-band – and a 1” (25mm) exit high frequency (HF) compression driver for clarity of vocal and high frequency projection. The HF section delivers consistent coverage in either plane from a user-rotatable horn.

When coupled with the Zone series, a ZonePad and the WebApp makes setting up a system and end user control simple and intuitive.

Features

  • Portrait or landscape mounting options
  • Rotatable high-frequency horn
  • 58Hz – 18kHz frequency response ±3dB
  • Maximum SPL 126dB (continuous), 132dB (peak)
  • 80° horizontal x 50° vertical coverage

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential

Cuboid 12

Cuboid 12

Two-way, full range, passive, 12" loudspeaker

Cuboid 12 is a full range, two-way, passive, 12” loudspeaker designed to perform. For applications requiring that extra power and performance, it effortlessly delivers rich and detailed sound with punch and precision.

With its steel grille and optional mounting hardware the professionally presented Cuboid 12 can be fixed in either portrait or landscape mode for a flexible, simple installation.

Cuboid 12 features a 12” (300mm) low frequency (LF) driver – for added bass performance and mid-band – and a 1” (25mm) exit high frequency (HF) compression driver for clarity of vocal and high frequency projection. The HF section delivers consistent coverage in either plane from a user-rotatable horn.

When coupled with the Zone series, a ZonePad and the WebApp makes setting up a system and end user control simple and intuitive.

Features

  • Portrait or landscape mounting options
  • Rotatable high-frequency horn
  • 62Hz – 20kHz frequency response ±3dB
  • Maximum SPL 123dB (continuous), 129dB (peak)
  • 80° horizontal x 50° vertical coverage

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential

Cuboid 10

Cuboid 10

Two-way, full range, passive, 10" loudspeaker

Cuboid 10 is a full range, two-way, passive, 10” loudspeaker designed to outperform its compact size. For short to medium throw distances, it effortlessly delivers rich and detailed sound with punch and precision.

With its steel grille and optional mounting hardware the professionally presented Cuboid 10 can be fixed in either portrait or landscape mode for a flexible, simple installation.

Cuboid 10 features a 10” (250mm) low frequency (LF) driver – for impressive bass and mid-band – and a 1” (25mm) exit high frequency (HF) compression driver for clarity of vocal and high frequency projection. The HF section delivers consistent coverage in either plane from a user-rotatable horn.

When coupled with the Zone series, a ZonePad and the WebApp makes setting up a system and end user control simple and intuitive.

Features

  • Compact size
  • Portrait or landscape mounting options
  • Rotatable high-frequency horn
  • 65Hz – 20kHz frequency response ±3dB
  • Maximum SPL 120dB (continuous), 126dB (peak)
  • 90˚ horizontal x 50˚ vertical coverage

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential

Cuboid 8

Cuboid 8

Two-way, full range, passive, 8" loudspeaker

Cuboid 8 is a full range, two-way, passive, 8” loudspeaker designed to outperform its compact size. For short to medium throw distances, it effortlessly delivers rich and detailed sound with punch and precision.

With its steel grille and optional mounting hardware the professionally presented Cuboid 8 can be fixed in either portrait or landscape mode for a flexible, simple installation.

Cuboid 8 features an 8” (200mm) low frequency (LF) driver – for impressive bass and mid-band – and a 1” (25mm) exit high frequency (HF) compression driver for clarity of vocal and high frequency projection. The HF section delivers consistent coverage in either plane from a user-rotatable horn.

When coupled with the Zone series, a ZonePad and the WebApp makes setting up a system and end user control simple and intuitive.

Features

  • Discreet size
  • Portrait or landscape mounting options
  • Rotatable high-frequency horn
  • 65Hz – 20kHz frequency response
  • Max SPL 115dB (cont), 121dB (peak)
  • 90˚ horizontal x 50˚ vertical coverage

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential

Cuboid

Cuboid

On-wall loudspeakers

Cuboid is a series of full range, two-way, passive loudspeakers designed for short to medium throw distances, delivering rich and detailed sound with punch and precision, at a cost competitive price point.

Comprising an 8”, 10”, 12” and 15”, their wooden enclosure and steel grille provide a professional look that can be fixed in either portrait or landscape mode with flexible mounting hardware providing for a clean and simple installation.

Each loudspeaker provides an impressive bass and mid-band with clarity of vocal and high note projection. Consistent coverage in either plane is achieved from a user-rotatable horn.

For enhanced bass performance they can be teamed with the Sub Series and the SmartAmp series will provide optimal sound settings as well as limiters to protect the drivers when playing at louder sound levels. In addition, a ZonePad and the WebApp makes setting up a system and end user control, simple and intuitive.

Features

  • Wooden cabinet, full range, two-way passive loudspeakers
  • Portrait or landscape orientation with user-rotatable horn
  • Rich and detailed sound quality at a competitive price point

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential

Up 6

Up 6

Two-way passive, full-range 6” ceiling speaker

Up 6 is a no-compromise two-way, passive 6” ceiling speaker delivering consistent coverage and full frequency sound to a wide range of cost conscious, commercial environments that require higher sound pressure levels — from hotels and concourses to retail outlets, bars and restaurants.

An integral fixing system is included to achieve a simple and clean installation.  Up 6 has a steel back can and perforated steel grille and is finished in neutral white.

Up 6 features a 6” (162mm) low frequency driver paired with a 0.7” (20mm) silk dome tweeter. It is suitable for both high quality speech and music reproduction.  A conical 110° coverage pattern ensures consistent, high performance sound where it needs to go.

Each Up 6 can be run on a variety of 70 or 100 volt taps, or at low impedance. The 16 ohm setting allows up to four units to be connected to each amplifier channel at low impedance. Tap selection is via a rotary switch behind the removable grille.

SmartAmps or Zone will provide optimal performance and loudspeaker protection. When coupled with the Zone series, a ZonePad and the WebApp makes setting up a system and end user control simple and intuitive.

Features

  • 6” coaxial driver
  • Discreet size
  • Unobtrusive design
  • 8 ohm or 70/100V line operation
  • Range of power taps
  • Wide conical coverage pattern
  • Integrated mounting hardware

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential

Up 4

Up 4

Two-way passive, full-range 4” ceiling speaker

Up 4 is a discreet, two-way 4” ceiling speaker delivering consistent coverage and full frequency sound to a wide range of cost conscious, commercial environments — from hotels and concourses to retail outlets, bars and restaurants.

An integral fixing system is included to achieve a simple and clean installation.  Up 4 has a steel backcan and perforated steel grille and is finished in neutral white.

Up 4 features a 4” (105mm) low frequency driver paired with a 0.7” (20mm) silk dome tweeter. It is suitable for both high quality speech and music reproduction. A conical 120° coverage pattern ensures consistent sound where it needs to go.

Each Up 4 can be run on a variety of 70 or 100 volt taps, or at low impedance. Tap selection is via a rotary switch behind the removable grille.

SmartAmps or Zone will provide optimal performance and loudspeaker protection. When coupled with the Zone series, a ZonePad and the WebApp makes setting up a system and end user control simple and intuitive.

Features

  • 4” coaxial driver
  • Discreet size
  • Unobtrusive design
  • 8 ohm or 70/100V line operation
  • Range of power taps
  • Wide conical coverage pattern
  • Integrated mounting hardware

Applications

  • Bars/Restaurants & Cafes
  • Retail
  • Wedding Venues
  • Hotels
  • Education Facilities
  • Houses of Worship
  • Corporate Offices
  • Museums
  • Fitness Studios
  • Residential
