Small Round & Square

Visual Performance Series

Small footprint to minimize visual impact.
Round or square aesthetic (by utilizing square adapters) to match downlights.
Create a system with four or more speakers in addition to a BPS-8 Bandpass Subwoofer for better coverage and exceptional sonic performance.
Independently pivoting tweeter allows speakers to be placed where they look the best while directing sound for best the performance.
Three performance levels to accommodate any ear or budget.

	VP42R	VP46R	VP48R
	VP42R +VP4SQ	VP46R +VP4SQ	VP42R +VP4SQ
Tweeter	1″ (25mm) cloth dome, Ferrofluid-cooled, pivoting, in acoustic back chamber	1″ (25mm) powder-coated aluminum dome, Ferrofluid-cooled, pivoting, in acoustic back chamber	1″ (25mm) ceramic dome, Ferrofluid-cooled, pivoting, in acoustic back chamber
Woofer	4 1/2″ (114mm) textured polypropylene cone with a rubber surround	4 1/2″ (114mm) Kevlar/Nomex laminated cone with a rubber surround	4 1/2″ (114mm) carbon fiber/Rohacell laminated cone with a rubber surround
Frequency Response	60Hz – 20kHz ±3dB	58Hz – 20kHz ±3dB	50Hz – 20kHz ±3dB
Impedance	8 ohms nominal; 6 ohms minimum	8 ohms nominal; 6 ohms minimum	6 ohms nominal; 4 ohms minimum
Power Handling	5 watts minimum; 70 watts maximum	5 watts minimum; 80 watts maximum	5 watts minimum; 100 watts maximum
Sensitivity	89dB SPL (2.83V/1 meter)	90 dB SPL (2.83V/1 Meter)	90dB SPL (2.83V/1 meter)
Shipping Weight	6 lbs (2.8kg) pair	6 lbs (2.8 kg) pair	6 lbs (2.8kg) pair
