Visual Performance Series

ThinLine

  • 34% shallower than standard-depth Visual Performance Series models.
  • Pivoting tweeter.*
  • Perfect for restricted mounting depths or obstructions found during installation where a conventional speaker is too deep.
  • Identical size cutout and grille for a perfect aesthetic match to other Visual Performance Series speakers.

*excluding VP62R SST/ SUR TL

VP62R SST/SUR TL
VP62R TL
VP66R TL
VP66 TL
VP52R UTL
Tweeter
Two 1″ (25mm) cloth domes, Ferrofluid-cooled, in acoustic back chamber
1″ (25mm) cloth dome, Ferrofluid-cooled, pivoting, in acoustic back chamber
1″ (25mm) powder-coated aluminum dome, Ferrofluid-cooled, pivoting, in acoustic back chamber
1″ (25mm) powder coated aluminum dome, Ferrofluid-cooled, pivoting, in acoustic back chamber
1″ (25mm) cloth dome, Ferrofluid-cooled, in acoustic back chamber
Woofer
6 1/2″ (165mm) textured polypropylene cone with a rubber surround
6 1/2″ (165mm) textured polypropylene cone with a rubber surround
6 1/2″ (165mm) Kevlar/Nomex laminated cone with a rubber surround
6 1/2″ (165mm) Kevlar/Nomex laminated cone with a rubber surround
5 1/4″ (133mm) polypropylene cone with a rubber surround
Frequency Response
45Hz – 20kHz ±3dB
45Hz – 20kHz ±3dB
43Hz – 20kHz ±3dB
43Hz – 20kHz ±3dB
75Hz – 20kHz +/- 3dB
Impedance
8 ohms nominal; 6 ohms minimum
8 ohms nominal; 6 ohms minimum
8 ohms nominal; 6 ohms minimum
8 ohms nominal; 6 ohms minimum
8 ohms nominal; 6 ohms minimum
Power Handling
5 watts minimum; 125 watts maximum
5 watts minimum; 125 watts maximum
5 watts minimum; 140 watts maximum
5 watts minimum; 140 watts maximum
5 watts minimum; 80 watts maximum
Sensitivity
89dB SPL (2.83V/1 meter)
89dB SPL (2.83V/1 meter)
90dB SPL (2.83V/1 meter)
90dB SPL (2.83V/1 meter)
89dB SPL (2.83V/1 meter)
Speaker Depth
3 5/32″ (80mm)
3 5/32″ (80mm)
3 5/32″ (80mm)
2 1/2″ (64mm)
1 7/16″ (36.2mm)
Dimensions
9 3/4″ (248mm)
9 3/4″ (248mm)
9 3/4″ (248mm)
8 3/8″ x 12 1/4″ (213mm x 311mm)
9 3/4″ (248mm) Diameter
Cut-Out Dimensions
8 1/4″ (210mm)
8 1/4″ (210mm)
8 1/4″ (210mm)
6 15/16″ x 10 3/4″ (176mm x 273mm)
8 1/4″ (210mm) Diameter
Grille Material
Perforated steel
Perforated steel
Perforated steel
Perforated steel
Perforated steel
Shipping Weight
5 lbs (2.3kg) each
9 lbs (4.1kg) pair
9 lbs (4.1kg) pair
9 lbs (4.1kg) pair
9 lbs (4.1kg) pair
