Reference Series

In-Ceiling

  • Purpose-built design to bring out the best in movies, TV, gaming and multimedia content.
  • Angled driver design for accurate imaging and clear dialogue.
  • Integrated enclosure for amazing performance and reduced disturbance into adjoining rooms.
  • Designed to fit into a standard ceiling cavity.
  • Mix and match with Reference Series in-wall speakers to achieve optimal sound in any room layout.
  • Provides a consistent aesthetic with other Reference Series speakers.
  •
R1C
R1CSUR
Tweeter
1″ (25mm) Ceramic dome, Ferrofluid-cooled in an acoustic back chamber
Two 1″ (25mm) Ceramic domes, Ferrofluid-cooled
Midrange
5 1/4″ (133mm) Carbon fiber/Rohacell laminated cone with a rubber surround
Two 3″ (76mm) Carbon fiber/Rohacell laminated cones with rubber surrounds
Woofer
Two 5 1/4″ (133mm) Carbon fiber/Rohacell laminated cones with rubber surrounds
Two 5 1/4″ (133mm) Carbon fiber/Rohacell laminated cones with rubber surrounds
Frequency Response
70Hz – 30kHz ±3dB
70Hz – 30kHz ±3dB
Impedance
8 ohms nominal; 6 ohms minimum
8 ohms nominal; 6 ohms minimum
Power Handling
5 watts minimum; 150 watts maximum
5 watts minimum; 150 watts maximum
Sensitivity
90dB SPL (2.83V/1 meter)
90dB SPL (2.83V/1 meter)
Shipping Weight
15 lbs (7.0kg) each
15 lbs (7.0kg) each
Cut-Out Dimensions (LxH)
12 3/8″ (314 mm) x 12 3/8″ (314 mm)
12 3/8″ (314 mm) x 12 3/8″ (314 mm)

Shared Specifications

13 25/32″ (350mm) x 13 25/32″ (350mm) x 7 9/16″ (192mm)


12 3/8″ (314 mm) x 12 3/8″ (314 mm)
