SP26

Loudspeaker Processor

The SP26 is a fully featured 2-IN/6-OUT digital speaker management system. Featuring 2 analog inputs and 6 analog outputs, each managed by a powerful DSP Engine. Each input channel provides PEQ, gain control, Dynamic Low boost, noise gate function, RMS compressor, internal White/Pink Noise Generator, and configurable delay. Each output offers up to 7 PEQ and crossover filters. Easy setup is assured with intuitive front panel controls and an interactive LCD display for local setup, or a dedicated PC control interface for remote monitoring and configuration via USB or RS485. The SP26 loudspeaker processor is the perfect counterpart to any HH speaker system, suitable in an array of applications, such as live sound, indoor/outdoor events, public address, theatrical performance, and touring. It also comes with expertly created audio pre-sets for use with the TNA line array system, for easy setup straight out of the box.

SPECIFICATIONS

  • Inputs
    Two Electronically Balanced XLR Inputs. RS485 XLR
  • Outputs
    Six Electronically Balanced XLR Outputs. RS485 XLR
  • Frequency Response
    20Hz-20kHz; -0.5dBy at 20Hz and 20kHz
  • S/N
    >106dBA
  • THD+N
    0.001% at 1kHz 0dBu
  • DSP
    Max Delay, 900 ms 10.4us increment/decrement steps per input channel. 340 ms 10.4us increment/decrement steps per output channel
  • Dimensions
    44 x 483 x 229mm, 1.7″ x 19″ x 9″
  • Weight
    3.5Kg, 7.7 lbs
  • Carton Dimensions (Hwd)
    9 x 53 x 30CM, 3.5″ x 20.9″ x 11.8″ , 0.014 M3
  • Packed Weight
    4.5Kg, 9.9 lbs
  • System Type
    Loudspeaker Management System
  • Power Consumption
    30W
  • Power Supply
    Universal voltage 100V-240V~ 50/60Hz
  • Other Controls
    Comprehensive front panel controls with quick mute functionality. Ground lift switches for signal and RS485/USB. USB interface.
  • AD-DA Converters
    24bit, 48KHz
  • Presets
    48 user presets
  • Filter Type
    Parametric EQ. 11 filters per input,7 filters per output. Bell, Shelving
  • Power Connector
    Removable IEC Power Cord C14
  • Filter Type
    Crossover. Butterworth 6/12/18/24/36/48 dB per octave. Bessel 12/24 dB per octave. Linkwitz-Riley 12/24/36/48 dB per octave

TESSEN TNA RAISES THE BAR FOR HH.

Since it’s conception in 1968, HH have delivered unparalleled engineering techniques with every product developed. The TNA line array range features outstanding quality and customisable options for live sound solutions. Included within the TNA range are the TNA-2051; dual 5 inch mid/high passive line array enclosure and the tna-1200s; 12-inch passive subwoofer. The TNA range provides choice solutions for live sound installation or portable, ground stacked front of house systems.

Powerful System Solutions

The SP26 loudspeaker processor is the perfect counterpart to any HH speaker system, suitable in an array of applications, such as live sound, indoor/outdoor events, public address, theatrical performance, and touring. It also comes pre-loaded with expertly created audio pre-sets for use with the TNA line array system, for easy setup straight out of the box.

Take Control

The SP26 features a dedicated PC control interface for remote monitoring and configuration via USB or RS485 connection.

Responsive Display

Easy setup is assured with a clear, responsive interactive LCD display for local setup.

Intuitive Control Surfaces

The SP26 features elegant, intuitive control surfaces. Making editing and storing presets simple and efficient.

GET CONNECTED

Featuring 2 analog inputs and 6 analog outputs, each managed by a powerful DSP Engine. Each input channel provides PEQ, gain control, Dynamic Low boost, noise gate function, RMS compressor, internal White/Pink Noise Generator, and configurable delay. Each output offers up to 7 PEQ and crossover filters.
