Introducing the world’s first

IoT-ENABLED PROFESSIONAL AMPLIFIERS

Introducing the CONNECTSERIES Half-Rack, perfectly suited for small to medium-scale installations our new half-rack models — CS34, CS64, CS124, CS34D, CS64D, and CS124D — feature direct HiZ (70V or 100V) or LoZ selectable by channel. With three ways to connect, you can engage the built-in Wi-Fi access point, connect to the venue’s Wi-Fi, or use the FAST Ethernet to connect to any local area network via Cat5 or Cat6 cable.

Then there’s the Cloud…the Network and Dante CONNECTSERIES Half-Rack is the first professional amplifier family to feature Cloud connectivity. Harness the power of the Cloud for remote control, monitoring, notifications, and more from any of your personal devices. Just connect your amp to a network and start commanding your systems.  Register for your free LEA Cloud account at leaprofessional.cloud

Features

  • Web Browser-based UI –  works on any device with no software to download
  • Direct LoZ and HiZ (70V or 100V) selectable per channel
  • Smart Power Bridge Double the power any any single channel without sacrificing other amp channels
  • Ways to Connect – 1. Built-in Wi-Fi Access Point 2. Existing Wi-Fi Network 3. Local Area Network
  • 96kHz Analog Devices DSP with Input Routing, multiple 48dB/Oct crossover filters, 8 Parametric EQ filters, user configurable speaker limiters, and real time load monitoring
  • Universal Switch Mode Power Supply with PFC. Operation from 100VAC – 240VAC +/-15%
  • Analog Balanced or Unbalanced Inputs Fully routable balanced or unbalanced RCA analog inputs via input matrix and input mixer in Web UI, SharkWare, or Cloud platform
  • External I/O Port for Remote ON/OFF and Fault Monitoring, and 4 General Purpose I/O ports coming soon
  • Highly Efficient Class D Output Stage for low AC Current draw
  • CLOUD CONTROL Remote control and monitoring from anywhere in the world — no VPN needed.

product range

Power ratings are stated on a per-channel basis. Ex: 80 Watts at 8 ohms = 80 Watts on each individual channel of the amplifier.
MODEL
CH COUNT
2Ω
4Ω
8Ω
25V
70V / 100V
CONNECT 34
4
15W
30W
30W
30W
30W
CONNECT 34D
4
15W
30W
30W
30W
30W
CONNECT 64
4
60W
60W
60W
60W
60W
CONNECT 64D
4
30W
30W
30W
30W
30W
CONNECT 124
4
60W
120W
120W
120W
120W
CONNECT 124D
4
60W
120W
120W
120W
120W
